Ladder Cable Trays
Ladder Cable Trays for Heavy-Duty Cable Management
Reliable support for power and industrial cables. Tell us your requirement, and our team will help you find the right ladder cable tray solution for your project.
Engineered for performance
Product Specifications
Materials, finishes and flange options available to meet different load requirements, installation environments and project specifications.
Raw Material
- MS (HR, CRC)
- Pre-Galvanized Steel
- Aluminium
- Stainless Steel 304
- Stainless Steel 316
Surface Finish
- Hot-Dip Galvanized
- GI Alkaline
- Pre-Galvanized
- SS 304 & 316
- Powder Coated
- Aluminium Anodized
Flange Options
- Regular Flange
- U Type Flange
- Inside Flange
- Outside Flange
- Heavy Duty Inside Flange
Features
Key Advantages of Ladder Cable Trays
Ladder cable trays provide strong cable support, easy cable access, effective ventilation and convenient maintenance for industrial and commercial installations.
High Load Capacity
Easy Maintenance
Easy Cable Installation
Strength & Durability
Excellent Ventilation
Flexible Cable Routing
Product Range
Custom sizes can be manufactured on request
| Width | Height | Thickness | Length |
|---|---|---|---|
| 150 | 50 / 75 / 100 / 150 / 200 | 1.6 / 2.0 / 2.5 / 3.0 | 2500 / 3000 |
| 200 | |||
| 250 | |||
| 300 | |||
| 350 | |||
| 400 | |||
| 450 | |||
| 500 | |||
| 550 | |||
| 600 | 2.0 / 2.5 / 3.0 | ||
| 650 | |||
| 700 | |||
| 750 | |||
| 800 | |||
| 900 | |||
| 1000 | |||
| 1200 | |||
| 1500 |
Frequently Asked Questions
Ladder cable trays are used to support and route power cables, control cables and other electrical wiring in industrial, commercial and infrastructure projects.
Ladder cable trays can be manufactured using MS (HR, CRC), pre-galvanized steel, aluminium, stainless steel 304 and stainless steel 316, depending on project requirements.
Ladder cable trays offer strong cable support, excellent ventilation, easy cable installation, convenient maintenance and flexibility for future cable additions.
Ladder cable trays are available in different widths, side rail heights and thicknesses to suit various installation requirements. Custom sizes can also be manufactured on request.
Yes, ladder cable trays are commonly used for heavy-duty cable installations. The appropriate tray design, material thickness, rung spacing and support span should be selected according to the cable load and project requirements.
